ATC ptr. Stepcraft HF 500, incl. electr. valva si switch box

Pret recomandat:
3231,69 RON TVA Inclus

In stoc producator
Cere termen de livrare
Nume:
Telefon:
Email:
Mesaj:
Scrieti codul
din imaginea
alaturata:
Inchide X

Cod: 10011



Detalii produs Inapoi

Automatic tool changer incl. Switch-Box


STEPCRAFT is the first desktop CNC system offering an automatic tool changer. Because the magazine can hold up to ten tools, the time-consuming, manual change of the tools is no longer necessary.

The assembly is very easy: The automatic tool changer is being tightend onto the spindle which in turn is being inserted into the SK 10 tool holding system with an ER 11 collet. It is held in the cone with a draw-in collet using spring power. During tool change a pneumatic cylinder presses onto this collet, thus, releasing the tool out of the cone. The tool changer attachment is constructed in a way that prevents the ingress of dust into its bearing.

Thanks to its modular design it is possible to enlarge the automatic tool changer: You can add up to five elements with each additional tool holder. This way, you can realize complex job much quicker and easier.

With the Switch-Box the time-consuming connecting and disconnecting of the different devices is no longer necessary. It offers space for the connection of up to eight accessories which can then be easily selected and started right away. The electronics module of the automatic tool changer is already installed in this Switch-Box.

For operating the tool changer attachment you are in need of a device to control the compressed air of the tool changer and blow-off function

Date tehnice

- Magazina poate sustine 5 scule aschietoare (poate fi extinsa pana la 10)
- Carcasa confectionata din aluminiu 7075 anodizat
- Axul confectionat din otel cu rulment dublu
- Concentricitate 0.02 mm
- Greutate (fara switch box) 357 g
- Forta de tensiune a arcului : 20 kg = aprox. 200 N
- Foloseste sistemul de prindere SK 10 cu bucsi elastice integrate
- Presiunea de operare: 8 bar
- 2 conectori pentru tuburi de 6 mm
- Diametrul de prindere de 43mm
- Recomandat pentru viteze de lucru de maxim 20.000 rpm
- Diametrul dispozitivului: 52 mm

Compatibil cu motorul STEPCRAFT HF 500.

Pachetul contine

1 x dispozitiv schimbare scule
1 x suport 5 scule
2 x adaptoare con SK10 pentru scule cu axul de prindere de ΓΈ 3.175 mm (1/8 ")
1x Switch-Box inclusiv 1 x modul electronic pentru dispozitvul de schimbare scule

Greutate

0.62 Kg

Video 1
